0.9 Litres Vaccine Carrier

Name: 0.9 Litres Vaccine Carrier
Brand: IVS ENTERPRISES
Price: 650 INR
Availability: InStock

Price 650 INR/ Piece

Get a Price/Quote

MOQ : 50 Pieces

0.9 Litres Vaccine Carrier Specification

Material
HDPE

Volume
0.9 Litres

Type
Others

Length
Approx. 21 cm

Height
Approx. 20 cm

Capacity
0.9 litres

Internal Dimension
25*18*21.4 cms

External Dimension
21.0 x 21.0 x 20.0 cm (L x W x H)

Coating
Polyurethane insulated inner lining

Weight
2.27 Kg Kilograms (kg)

Use
Safe storage and transportation of vaccines at required temperatures in outreach immunization programs

Application
Ideal for routine immunization, field operations, and cold chain maintenance

Lid Type
Tight fitting, leak-proof lid with locking mechanism

Carrying Handle
Strong, ergonomic carrying strap for easy handling

WHO Performance Standard
Complies with WHO/UNICEF PQS E004/VC01.1 requirements

Cold Life
More than 24 hours at +43°C ambient temperature with fully conditioned ice packs

Color
Blue (standard color, may vary)

Number of Ice Packs Required
2 to 4 standard ice packs (0.4 L each)

Temperature Range
Maintains 2°C to 8°C for the duration of cold life

0.9 Litres Vaccine Carrier Trade Information

Minimum Order Quantity
50 Pieces

Supply Ability
500 Pieces Per Month

Delivery Time
10 Days

About 0.9 Litres Vaccine Carrier

Product details

External dimensions	251821.4 cms
Insulation thickness	32-38 MM
Insulation material	CFC-Free Polyurethane
Internal lining material	HIPS
External surface material	HDPE
Weight empty	1.46 Kgs
Weight fully loaded	2.27 Kg
Cold life without openings(hrs at 43C)	21.5 Hours
Number of Ice Packs	2
Vaccine Storage Capacity	0.9 Litres

Technical Details

Designed for Reliable Vaccine Transport

Engineered to support routine immunization efforts, this carrier combines robust construction with effective insulation, ensuring vaccines remain at a safe temperature during transit. Its compliance with WHO/UNICEF standards guarantees trust in national health programs.

Maintains Stable Temperatures on the Go

With a cold life exceeding 24 hours at high ambient temperatures, this carrier provides consistent cooling using standard ice packs. The tight-sealing lid and polyurethane insulation work together to keep sensitive vaccines at 2C to 8C.

User-Friendly Features and Durable Build

Made from high-density polyethylene (HDPE), this carrier offers durability for frequent field use. The ergonomic carrying strap, leak-proof locking lid, and manageable 2.27 kg weight ensure both convenience and efficiency in challenging environments.

FAQ's of 0.9 Litres Vaccine Carrier:

Q: How do I prepare the 0.9 Litres Vaccine Carrier for use?

A: To prepare the vaccine carrier, insert 2 to 4 standard ice packs (0.4 L each) fully conditioned in a freezer. Arrange the ice packs inside the carrier according to the provided instructions to achieve optimal cold life before placing the vaccines in the carrier.

Q: What is the recommended application for this vaccine carrier?

A: This vaccine carrier is ideal for routine immunization activities, field operations, and maintaining cold chain conditions during vaccine outreach programs, particularly in settings where maintaining temperature stability is critical.

Q: When should I replace the ice packs inside the carrier?

A: Ice packs should be replaced after the carrier's cold life has elapsed, typically more than 24 hours at +43C, or sooner if the internal temperature exceeds the recommended 2C to 8C range. Always monitor the internal temperature to ensure vaccine safety.

Q: Where can this vaccine carrier be used effectively?

A: This carrier is suitable for transport in clinics, health camps, remote locations, or urban field sites, providing reliable cold chain maintenance whenever direct refrigeration is unavailable.

Q: What benefits does the tight-fitting lid and locking mechanism provide?

A: The secure, leak-proof lid with a locking mechanism prevents accidental spills, heat ingress, and temperature fluctuations, ensuring the vaccine's efficacy is preserved throughout transit.

Q: How does the carrier comply with global health standards?

A: The carrier meets the WHO/UNICEF PQS E004/VC01.1 requirements for vaccine carriers, ensuring its suitability for use in international immunization and vaccine delivery programs.

Q: What materials are used, and how do they enhance performance?

A: Constructed from high-density polyethylene (HDPE) with a polyurethane insulated inner lining, the carrier offers excellent durability, thermal insulation, and protection for sensitive vaccines during transport.
